4″ Square SHADE Mini Color Selectable LED Light with Black Trim and Specular Baffle Color by Liteline

Description

The 4″ SHADE MINI is an 8 watt 4″ round downlight for retrofit application onto 4″ octagon box. It is a high-performance, easy to install residential grade downlight solution that offers good light output, energy-efficiency and streamlined design. Suitable for wet locations.

• Body – Durable airtight aluminum body with mounting holes. On-face magnets allows for securely attaching a selection of 2-tone, dead front trim/baffle combinations. Available in a variety of color/finish combinations.
• LED Characteristics – This general application light fixture features an 8 watt LED module that maintains uniform intensity producing up to 560 lumens; with a typical CRI of 90. Available with 5 step CCT switch (2700K, 3000K, 3500K, 4000K, 5000K).
• Dimming – 100%-10% dimming capability. This fixture is compatible with industry standard forward/reverse phase dimmers, TRIAC/ELV dimmers. For compatible dimmers, visit /SHADEMINI
• Beam Spread – The fixture lens provides 100° beam spread.
• Mounting – Attached to an industry standard 4″ octagon boxes with minimum depth of 1.5″ (38mm) via mounting holes.
• Environment – Suitable for wet locations, Fire-rated when used in a fire-rated octagon box, Indoor/Outdoor rated.
• LED Driver – Built-in on board driver with 40mA output and 100-135V AC input.
