Description
NUVO Under Cabinet Light — White & Selectable CCT
The NUVO 63-504 is a white under cabinet light fixture crafted from aluminum, measuring 28 in. in length. This fixture features an integrated LED light source, delivering 1366 lumens at 120V with selectable color temperatures of 3000K, 4000K, and 5000K.
Key Features
- Dimensions: 28 in. length, 3.5 in. width, 1 in. height.
- Voltage: Operates at 120V with a power factor of >0.9.
- Wattage: Consumes 17 watts, equivalent to an 80W incandescent bulb.
- Lumens: Provides 1216 to 1366 lumens for ample illumination.
- CCT: Selectable 3000K, 4000K, 5000K for varied lighting needs.
- CRI: High color rendering index of 90+ for accurate color representation.
- Lifespan: Rated for 50,000 hours of operation.
- Beam Angle: Wide 105-degree beam angle for broad coverage.
- Dimming: Compatible with multiple dimming types including forward and reverse phase.
- Material: Constructed from aluminum with a frosted white polycarbonate lens.
- Finish: White finish for a clean, modern look.
- Compliance: cETLus listed and ROHS compliant.
Core Design & Profile
This under cabinet light features a slim profile with a white aluminum housing and a frosted polycarbonate lens. It is designed for dry locations and offers a modern utility style.
LED Illumination & Performance
With an output of 1366 lumens and a consumption of 17 watts, this fixture provides efficient lighting. The selectable CCT ranges from 3000K to 5000K, allowing for warm to natural light settings.
Power, Wiring & Linkability
The fixture operates at 120V and is dimmable. It supports direct wiring and can connect up to 22 units for extended runs.
Where This Fixture Works Best
- Kitchen under cabinets
- Office workstations
- Retail displays
- Workshop task lighting
- Study areas
What’s Included
- 1 x NUVO 63-504 LED Under Cabinet Light
