RAB C-WALLS Field-Adjustable LED Wall Pack — 17/25/32W Selectable, 120–277V
The RAB C-WALLS is a highly versatile, small-sized LED wall pack delivering up to 4,349 lumens with field-selectable 17W/25W/32W output and adjustable 3000K/4000K/5000K color temperatures. Operating on a 120–277V universal driver, this luminaire comes standard with an integrated on/off photocell for automated dusk-to-dawn operation. Built with a Wet Location rating and DLC Premium listing, it provides an ultra-durable, adaptable lighting solution for building entryways, perimeters, and walkways.
Key Features
- Selectable Wattage: 17W / 25W / 32W (25W default)
- Selectable CCT: 3000K / 4000K / 5000K (4000K default)
- Delivered Lumens: 2,066 to 4,349 lumens
- Voltage: 120–277V input
- Dimming: 0–10V dimming (dims down to 10%)
- Controls: Integrated on/off photocell
- CRI: 81-84
- Environmental Ratings: Suitable for wet locations
- Certifications: UL Listed, TAA Compliant, DLC Premium Listed
- Estimated Life: 100,000 hours (L70 / TM-21 calculations)
Typical Applications
- Building entryways and doorways
- Perimeter and security lighting
- Pedestrian walkways
- Commercial and residential exteriors
Performance & Light Output
This compact wall pack provides scalable illumination ranging from 2,066 to 4,349 lumens depending on the selected wattage and color temperature, achieving an excellent efficacy of up to 136.6 lumens per watt. It features a bio-based Polymethyl Methacrylate (PMMA) lens that ensures smooth, uniform light distribution. The high-performance, surface-mount LEDs deliver consistent color with a CRI over 80 and maintain a highly prolonged rated life of 100,000 hours based on TM-21 calculations.
Electrical & Controls
This fixture operates on a constant current 120–277V AC driver with standard 0–10V dimming functionality (requires a separate 0-10V DC dimming circuit to operate, dims down to 10%). The electrical components are securely protected by built-in 4KV surge protection. To maximize energy savings out of the box, the C-WALLS includes an integrated on/off photocell enabling hands-free dusk-to-dawn operation without the need for external sensors.
Construction & Durability
Engineered for tough outdoor environments, the luminaire features a housing made from recycled aluminum and sheet metal, finished in a high-durability, long-lasting bronze color. It carries a UL listing for wet locations, indicating protection against water ingress. The fixture operates reliably in extreme temperatures, starting as low as -40°C (-40°F) and handling ambient heat up to 40°C (104°F).
Installation & Mounting
The C-WALLS is designed for simple surface mounting. Its compact dimensions (8-5/8″ H x 9-1/4″ W x 2-3/4″ D) and light weight (1.87 lbs) make it exceptionally easy to handle and install over recessed junction boxes, utilizing its 3 conduit entry points.
What’s Included
- RAB C-WALLS LED Wall Pack Fixture (Bronze)
- Integrated Photocell
