Description
RAB CRX4 4 in. Smooth Downlight — 20W / Selectable CCT
The RAB CRX4 is a versatile 4-inch commercial downlight delivering up to 2,000 lumens using 20W. This fixture offers selectable color temperatures ranging from 2700K to 5000K, making it ideal for various lighting needs. Designed for both new construction and retrofit applications, it features a smooth trim and is wet rated for outdoor use.
Key Features
- Wattage Options: 12W, 16W, 20W
- Lumen Output: 1,200 to 2,000 lumens
- Color Accuracy: 90 CRI for true color rendering
- Beam Angle: 85°±10° for wide coverage
- Voltage: Operates on 120-277V
- Dimming: 0-10V and TRIAC/ELV dimming compatible
- Lifespan: 50,000 hours L70
- Compliance: Energy Star, Title 24 JA8, RoHS
- Construction: Metal enclosure with frosted polycarbonate lens
- Mounting: Recessed with remote driver/junction box
Construction & Aesthetics
The CRX4 features a smooth white trim and a frosted polycarbonate lens for even light distribution. It is constructed from durable metal and is air-tight certified. Optional interchangeable trims are available in matte black, brushed nickel, and bronze.
Electrical & Installation
This downlight operates on 120-277V and supports universal dimming. It includes a remote driver with a built-in junction box for easy installation. Compatible accessories include a 4-inch mounting plate and emergency driver.
Light Output & Performance
With a high color accuracy of 90 CRI and a beam angle of 85°±10°, the CRX4 ensures excellent light quality and coverage. It offers a long lifespan of 50,000 hours.
Typical Applications
- Commercial spaces
- Retail environments
- Hospitality settings
- Outdoor areas
- Residential applications
