Satco|Nuvo Beam Selectable LED Linear High Bay 15600lm 105W/90W/70W Selectable CCT 120-347V Suspended White

Description

Satco|Nuvo Beam Selectable LED Linear High Bay — 105W/90W/70W Selectable

The Satco 65-1510 is an innovative LED linear high bay offering beam selectable technology alongside 105W/90W/70W selectable wattage and up to 15,600 lumens. Operating on a universal 120-347V input, it provides contractors with unparalleled flexibility. The rugged 1.25 ft design ensures optimized lighting distribution for complex industrial layouts and warehousing setups.

Key Features

• Beam Selectable: 45°x100°, 65°x95°, or 90°x90° adjustable distribution.
• Wattage Selectable: 105W/90W/70W field-adjustable power options.
• CCT Selectable: 3000K, 4000K, and 5000K switchable color temperatures.
• Input Voltage: 120-347V universal operation.
• Light Output: Up to 15,600 lumens with a maximum 148 LPW efficacy.
• Dimming: Standard 0-10V continuous dimming.
• Environmental Rating: IP20 rated for damp locations.
• Lens: IK09 impact-resistant polycarbonate lens.
• Sensor Ready: Integrated sensor port for quick additions.

Typical Applications

• Warehouses
• Factories
• Commercial Facilities
• Gymnasiums
• Distribution Centers

Performance & Light Output

This luminaire delivers brilliant, consistent illumination ranging from 9,870 to 15,600 lumens with an outstanding maximum efficacy of 148 LPW. It features an 80 CRI LED array for clear visual acuity and a long-lasting 50,000-hour functional life. The standout feature is the physically adjustable beam distribution, allowing installers to set the light to 45°x100°, 65°x95°, or 90°x90° to optimize coverage for narrow racking aisles or open floor plans.

Electrical & Controls

Powered by a robust 120-347V driver, this fixture ensures broad compatibility across standard commercial power systems. It comes equipped with 0-10V continuous dimming functionality to maximize energy savings when paired with automated building controls. Additionally, it includes a 6kV surge protector and an integrated sensor port, making it ready for immediate occupancy or daylight sensor integration.

Construction & Durability

Built to endure demanding industrial environments, the fixture is constructed from rugged die-cast aluminum with a clean white finish. It utilizes a durable IK09 impact-resistant polycarbonate lens that protects internal LED components while ensuring uniform light distribution. The thermally efficient design maintains optimal operating temperatures from -40°C to 50°C, ensuring long-term reliability in damp locations.

Installation & Mounting

Engineered for rapid deployment in high-ceiling environments, this linear high bay supports standard suspended mounting configurations out of the box. It includes a 41 in. suspension kit, allowing contractors to efficiently secure the fixture without sourcing additional suspension hardware. A 1/2 in. knockout is also provided for secure wiring access.

What’s Included

• (1) LED Linear High Bay
• (1) 41 in. Suspension Kit
