Description
Keystone Technologies 85W Driver — 10-56V
The KTLD-85-UV-SC2600-56-VDIM-U4-USB is an 85W LED driver with an input voltage range of 120-277V and an output voltage of 10-56V DC. This Constant Current driver features 0-10V dimming and is housed in a durable metal enclosure. It is designed for indoor use and is dry rated.
Key Features
- Total Power: 85W
- Input Voltage: 120-277V
- Output Voltage: 10-56V DC
- Output Current: 860-2600mA
- Dimming: 0-10V
- Dimensions: 16.89 in. L x 1.18 in. W x 1.00 in. H
- Enclosure Type: Metal
- Class 2: Yes
- Certifications: UL, cUL, FCC, CE
Physical Design & Installation
The driver features a robust metal enclosure, ensuring durability and protection. It does not include an integrated junction box.
Dimming & Controls
Compatible with 0-10V dimming systems, this driver allows for smooth dimming down to 1% at maximum output current. It supports programmable output current and dimming levels via a USB-C connection.
Performance & Build
Equipped with over-voltage, over-current, short circuit, and over-temperature protection, this driver ensures reliable performance. It is Class 2 compliant and meets various safety standards.
Typical Applications
- Commercial Lighting
- Industrial Lighting
- Office Lighting
- Retail Lighting
